EXPLODE
26
※Parts indicated by "nsp" on this table cannot be supplied.
※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
P1 nsp PCB H/P ASSY 7028073933010 1
P3 nsp PCB USB ASSY 7028073932010 1
P4 nsp PCB FRONT ASSY 7028073931010 1
P6 nsp PCB INPUTHDAM CNT 7028073912010 1
P7 nsp PCB HDAM ASSY 7028073921010 1
P8 nsp PCB AMP ASSY 7028072971060 1
P9 nsp PCB GUIDE TOP 7028073936010 1
P10 nsp PCB GUIDE L 7028073934010 1
P11 nsp PCB FH GUIDE 7028073937010 1
P12 nsp PCB MAIN U 7028072921060 1
P12 nsp PCB MAIN N 7028072921070 1
P12 nsp PCB MAIN K 7028072921080 1
P13 nsp PCB INPUT 7028072951060 1
P14 nsp PCB FRONT CNT 7028072942060 1
P15 nsp PCB RS232C ASSY 7028072943060 1
P16 9U6391012800M PCB HDMI ASSY U 7028072981060 1
P16 9U6391012900M PCB HDMI ASSY N 7028072981070 1
P16 9U6391013000M PCB HDMI ASSY K 7028072981080 1
┗━━
P2
- PCB FRONT HDMI ASSY 7028072982060 1
P17 nsp PCB RC5 MX 7028073913010 1
P18 nsp PCB SMPS ASSY U 7028072961060 1
P18 nsp PCB SMPS ASSY N/K 7028072961070 1
P19 nsp PCB VIDEO ASSY 7028072941060 1
P20 nsp PCB PREOUT ASSY 7028073911010 1
1 963412100780M KNOB FUN BK 5080212691000S 2
1 963412100790M KNOB FUN SG 5087212691100S 2
2 963421006200M BADGE 5630210678000S 1
3 943424100270M DECORATION RING BK 5127210981000S 2
3 943424100280M DECORATION RING SG 5127210981100S 2
4 00M10BW355010 LENS POWER 3710211083000S 1
5 411510021005M BUTTON POWER BK 5090213961000S 1
5 963411012000M BUTTON POWER SG 5097213961100S 1
6 943423100290M LENS BUTTON 3710211183000S 2
7 416510046009M WINDOW DISPLAY 5070213183000S 1
8 416510047101M SHEET WINDOW 1217211562000S 1
9 943424100250M HOLDER WINDOW BK 4320211091000S 1
9 943424100260M HOLDER WINDOW SG 4320211091100S 1
10 nsp DECORATION WINDOW 5120210991000S 1
11 nsp PLATE RCA 4470212216000S 1
12 nsp PLATE USB 4470212206000S 2
13 943411101410M BUTTON 9KEY BK 5097214711000S 1
13 943411101420M BUTTON 9KEY SG 5097214711100S
14 nsp HOLDER REMOCON 4320211081000S 1
15 481510019100M LENS REMOCON
3710211173000S 1
16 963402104120M PANEL FRONT U1B 3067215281220S 1 * Ver.2
16 963402104130M PANEL FRONT N1B/K1B 3067215281230S 1 * Ver.2
16 963402104140M PANEL FRONT N1SG 3067215281310S 1 * Ver.2
17 943419100320M COVER RCA ASS'Y BK 4318215411010 1
17 943419100330M COVER RCA ASS'Y SG 4318215411110 1
19 nsp CLAMP 4330000310000S 1
20 nsp CUSHION SCREW 4050213025000S 3
21 nsp CUSHION CABINET SIDE 4050214795000S 2
22 90M46BW056010 CUSHION FOOT 4050211175000S 4
23 00M46BW057210 FOOT 4007210321000S 4
24 nsp CHASSIS MAIN 3200214626100S 1
25 nsp SUPPORT PCB 4070001601010S 2
28 nsp CHASSIS BACK U 3207214636400S 1
28 nsp CHASSIS BACK N 3207214636500S 1
28 nsp CHASSIS BACK K 3207214636510S 1
29 nsp SHEET RATING 1210211909000S 1
30 nsp SHEET HIMELON 1210211629000S 3
! 31 963101101570S TRANS MAIN U 8200960660850S 1
! 31 963101101580S TRANS MAIN N 8200960660860S 1
! 31 963101101590S TRANS MAIN K 8200960660870S 1
32 nsp BRACKET PCB 4010056906010S 5
33 nsp HEATSINK MAIN 2120212048000S 1
34 nsp
SHEET GRAY TOP 1210211362000S 1
35 nsp WASHER 1530210126000S 3
42 nsp BRACKET SMPS 401021488600DS 1
43 963403100710D CABINET TOP U1B, N1B, K1B 3007212026000S 1 Ver.3
43 963403100720D CABINET TOP N1SG 3007212026010S 1 Ver.3
A nsp SCREW(+2S 3X10 ZNW/BH) B020030101B10S 31
B nsp SCREW(+2S 3X6 ROUND BK/BH) B020230063B10S 1
C nsp SCREW(+2S 3X8 ZNW/BH) B020030081B10D 26
C nsp SCREW(+2S 3X8 WASHER PI 12 ZNW/BH) B020030081B10D 4
C nsp G121162400040S NUT B020030081B10D 10
D nsp SCREW(+3S 4X10 P+S WASHER ROUND ZNW/BH) 1500001456010S 1
F nsp G121162400040S NUT -
G nsp SCREW(+2S 3X14 P+S WASHER ZNW/HH) B028940101B11S 4
H nsp SCREW(+2S 3X17 ZNW/BH) B018230141H11D 21
I nsp SCREW(+2S 4X8 BK/BH DOT) B020030171B10S 2
J nsp SCREW(+2S 4X8 NI/BH DOT) 1500040083B10S 8
K nsp SCREW(+2S 3X10 BK/BH DOT) B020030103B11S 31
L nsp SCREW(+3S 3X6(DOT))BK/BH B020930063B10S 11
Q404 00D9630235301 2SD2560Y TOP3P 130W 15A/MICA-STRAIGHT J5032560Y0170S 1
Q409 963219003340S KTC3964/TO126S-BULK J502396400010S 1
Q410 00D9630235204 2SB1647Y TO3P/130W 15A(WITH MICA) J5011647Y0170S 1
Q416 00D9630235301 2SD2560Y TOP3P 130W 15A/MICA-STRAIGHT J5032560Y0170S 1
Q421 963219003340S KTC3964/TO126S-BULK J502396400010S 1
Q422 00D9630235204 2SB1647Y TO3P/130W 15A(WITH MICA) J5011647Y0170S 1
Q428 00D9630235301 2SD2560Y TOP3P 130W 15A/MICA-STRAIGHT J5032560Y0170S 1
Q433 963219003340S KTC3964/TO126S-BULK J502396400010S 1
Q434 00D9630235204 2SB1647Y TO3P/130W 15A(WITH MICA) J5011647Y0170S 1
