PREOUT
159mVrms
+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
EXT IN
0dBFS
1.41Vrms
SR5008
NR1604/1504
LEVEL DIAGRAM
CENTER ch
-2dB
0dBFS
-10dBFS
-20dBFS
-30dBFS
-40dBFS
-20dBFS(DIG.IN)
PCM or DD Config1
-26.5dBFS(A/D IN)
200mV
+30dB
SP OUT
4.48Vrms/8Ω
+
29dB
MAX SIGNAL LEVEL
DOLBY LIMIT LEVEL (ALLch-3dBFS)
+3dB
-26.5dBFS(DIG.IN)
DD Config2
-2+6.5=4.5dB
＋
EXT IN
＋
SPEAKER
DSP
R2A15218FP
GAIN
(SR5008 ONLY)
PCM1690
D/A
－
－
＋
PLD
PRE OUT MUTE
(SR5008 ONLY)
99
