Mark 7 APEX 10 - Case Feeder Droptube and Spring Assy

14
Mark 7® Reloading APEX 10 User Manual version 1.0, Copyright 2021
All rights reserved
Install the spring assembly between the Case Feeder housing and the Case Feed adapter as shown
below. The “bayonet” style funnel attachment makes the Feeder Spring easy to remove and attach, simply
slide it over the lugs and turn slightly.
Figure 9: Case Feeder Assy Installed
Case Feeder Spring Assy
