7. Tool Head Recommended Die Positions
With 9 available Tool Head die locations there are many setups the Apex 10
TM
can be
configured/customized for to achieve your loading/processing requirements. We recommend the
following setup for standard processing and loading in one pass.
Figure 15: Tool Head Recommended Die Positions
Station 1:
Case feed
Station 10:
Bullet Crimp
(Die Not Included)
Station 9:
Bullet Seat
(Die Not Included)
Station 8:
Bullet Drop
(Not Included)
n
N
Station 7:
Powder Check
(Die Not Included)
Station 6:
Powder Drop
Station 5:
Case neck Expansion
Expander die
(Die Not Included)
Station 4:
Size/Prime
(Remove decap rod
from sizing die, sizing
die not included)
Station 3:
Trim / Swage Back up
(Hold Down Die Included)
Station 2:
Decapping
(Die Not Included)
