Case Feeder Adapter and Drop Tube Assy installation
Install the Case Feed Adapter with shoulder screw and socket cap screw provided to the Case Feed
Upper Housing. The Case Feed Adapter is designed to rotate out 90 degrees for quick removal of cases in
the Drop Tube assy.
Figure 8: Case Feed Adapter installation.
Mounting Hardware
Drop Tube
(O-ring facing down)
