Case Feeder Funnel Adjustment: Above the opening of the case funnel there is a door that can be adjusted
for opening size. Start with the door in a center location. Adjust the opening to increase or decrease as
needed to allow cases to cleanly drop into the funnel. The opening may need to vary depending on case
length and motor speed.
Figure 7: Adjusting Case Feeder Outputs
Case Feeder
Funnel Adjustment
Case Feeder
Door Adjustment
