Operating Instructions
Once the machine is fully assembled and setup we recommend the following steps to configure the
press for operation
• Determine intended use of machine (processing, loading, processing/loading combined and setup
press accordingly – please feel free to contact us to discuss your requirements.
• Thread the dies into Tool Head but do not set final adjustments at this time – keep dies partially
backed off.
• Cycle the machine a few times without components to ensure smooth operation and proper
indexing.
1. Case feed - sizing/decapping – Station 1 and 2
Add cases to the Case Feeder in the caliber that you are loading. (Up to about 400 9mm cases or until
bowl is about 1/3 full.) Before powering on we recommend detaching case drop tube from the press and
directing it into a bucket and running the Case Feeder continuously while watching the cases inside the
bowl. The feed plate is equipped with a clutch mechanism to allow the plate to slip in case of a jam or
over-load situation. It is factory set; however, adjustment may be required at times. The clutch should be
tight enough to allow the plate to rotate with a normal load of cases but slip if an additional load occurs.
Note: never fully tighten down the clutch as this could damage the motor. Adjust the opening in the sliding
door as needed. The height of the case funnel can also be adjusted up or down as needed, however the
factory setting usually works fine for most calibers. The motor speed is adjustable also. Start with the
speed at mid-range. This will work for hand operation of the press. If an AutoDrive unit was added, then
a faster speed may be required. Note that the Case Feeder is also equipped with a reverse button. If cases
were to jam inside the bowl, the motor can be reversed in direction to clear it. Press the button once to
make the shell plate turn in reverse and press it again to return to the normal clockwise direction.
Once the Case Feeder is dialed in and the cases are feeding properly re-connect the case drop tube to
the press and run a few cases into the machine. Run cases around the shell plate to ensure proper
feeding. Install the Akro bin provided with the press to catch the cases as they offload.
Remove the cases from the shell plate and move the Tool head to the down position. Thread the
decapping die down until it lightly touches the shell plate. Lock the die in position. Connect the spent
primer offloading hose.
