Martin smartMAC User Manual

DMX protocol 37
DMX protocol
8-bit
mode
16-bit
mode
DMX Value Percent Function
11
0 - 14
15 - 29
30 - 39
40 - 49
50 - 72
73 - 79
80 - 99
100 - 119
120 - 123
124 - 127
128 - 147
148 - 167
168 - 187
188 - 190
191 - 193
194 - 196
197 - 199
200 - 202
203 - 207
208 - 217
218 - 227
228 - 237
238 - 247
248 - 255
0 - 5
6 - 11
12 - 15
16 - 19
20 - 28
29 - 31
31 - 39
40 - 47
47 - 48
49 - 50
50 - 58
58 - 65
66 - 73
74 - 75
75 - 76
76 - 77
77 - 78
78 - 79
80 - 81
82 - 85
85 89
89 - 93
93 - 97
97 - 100
Shutter, strobe, reset, lamp on/off
Shutter closed
Shutter open
Shutter fade in
Shutter fade out
Strobe, fast → slow
Shutter open
Opening pulse, fast → slow
Closing pulse, fast → slow
Shutter open
Music triggered shutter
Random strobe, fast
Random strobe, medium
Random strobe, slow
Shutter open
Random opening pulse, fast
Random opening pulse, slow
Random closing pulse, fast
Random closing pulse, slow
Shutter open
Reset fixture*
Shutter open
Lamp on
Shutter open
Lamp power off (hold for 5 sec.)**
22
0 - 255 0 - 100
Shutter fading
Shutter closed → open
Table 4: DMX Protocol
*If Reset fixture is disabled under
 →  in the control
menu, the reset command only
works if Color 8 is selected on
channel 3 (cont. or scroll) and
Gobo 6 is selected (rot. or
indexed) on channel 4.
A five-second delay for the Reset
fixture command can be set in the
control menu under
 →
.
**If DMX Lamp Off is disabled in
 →  in he control
menu, a lamp off command can
only be executed if Color 8 (cont.
or scroll) is selected on channel 3
and Gobo 6 (rot. or indexed) is
selected on channel 4.
