Martin smartMAC User Manual

46 smartMAC user manual
DMX capture menu
The DMX capture menu in  Æ Æ contains the following options:
Control panel shortcuts
The following shortcuts are available using the buttons in the smartMAC control panel:

To access
this menu,
hold
[Enter]
pressed for
a few
seconds


Enable pan/tilt position feedback/correction system

Disable pan/tilt feedback (this setting is not saved when fixture is
reset)

Effects adjustment menu (for service use: for full details of this
menu, see “Adjustment submenu” on page 47)

(OF = offset)

Shutter calibration

Color wheel calibration

Rotating gobo wheel calibration

Rotating gobo calibration

Focus calibration

Pan calibration

Tilt calibration
 
Load factory effects calibration settings
 
PCB test: for service use only
 
Manually set fixture to receive software upload
Item Item item Options Notes
  

Add the scene currently being sent by DMX to the end of the stand-alone
sequence.

Insert the scene currently being sent by DMX before the current scene.
Table 6: DMX capture menu
Shortcut Function
Hold [Menu] and press [Up] Resets fixture
Hold [Menu] and [Enter] during fixture reset Freezes pan and tilt
Hold [Up] and press [Down] Invert display
Hold [Enter] and press [Up] Power lamp on
Hold [Enter] and press [Down] Power lamp off
Table 7: Control panel shortcuts
Menu Item Options Notes (Default settings in bold print)
Table 5: Control menu
