Model: LC5296-AT /LC5248E-AT/LC5296V-AT masibus
Doc. Ref. no. : - m61C/om/301
Issue no. 13
User’s Manual Page 15 of 44
SET-1 Key
(Menu /
Enter
Key)
For Linear Output, Shows Alarm Set Point-1(A1.SP), if
pressed in RUN mode. And if pressed for few seconds
shows Control Set Point-1(C1.SP).
For Other Output Type, shows Control Set Point-1(C1.SP),
if pressed in RUN mode.
In Sub Menu it can be used to get to the next Parameter.
It is also used to save the parameters to nonvolatile
memory, when user setting a proper data by Increment
and decrement key for parameter configuration.
Shows Alarm Set Point-2(A2.SP), if pressed in RUN mode.
Shows Sok.t(Run/stop) if pressed two times in RUN mode.
It is used to switch between Auto to Manual mode and
Manual to Auto mode if pressed for at least 2 sec if
function key is A/M.
Shows remaining soak time when pressed if function key is
selected SOK.T.
PV
(Process
Value)
Display
4 digital 0.56 inch RED Display
Display process value.
Display parameter name when user set parameter.
Display error message when an error occurs.
4 digital 0.4 inch GREEN
Display set value.
Display parameter value of parameter in process value
field when user set parameter.
Display control output value when in manual mode.
ON when Relay-1 is energized & OFF otherwise.
ON when Relay-2 is energized & OFF otherwise.
ON when unit is in Manual mode.
OFF when unit in Auto Mode.
ON when device is transmitting some Data (RS-485).
ON when device is receiving some Data (RS-485).
5.3 Front Panel Description of LC5248E-AT/LC5296V-AT
Increment the Value of any Parameter.
Shows ambient value for T/C Input in RUN mode.
In Manual Mode this key is used to Increment the %Power.
Decrement the Value of any Parameter.
Shows %Power value if Device is in Auto Mode in RUN
mode.
In Manual Mode this key is used to Decrement the
To Next Page
