Masibus LC5296-AT User Manual

Model: LC5296-AT /LC5248E-AT/LC5296V-AT masibus
Doc. Ref. no. : - m61C/om/301
Issue no. 13
User’s Manual Page 21 of 44
6.3 RUN Time Indication/Function
Following parameters can view or change during run time.
 Press Decrement key to show percentage power Auto Mode (0.0 to 100.0%)
 For Thermocouple input type, Press Increment key to show ambient
temperature.
 During manual mode, Increment key and Decrement Key will use to
modify the percentage power.
 Press to toggle between AUTO & MANUAL mode or display time.
6.4 Set Point Setting
*Last decimal point of PV display “ON”, indicates RUN.
6.5 AUTO TUNE MODE
6.4 Set Point Setting Set Point Sett in g:
Parameter
(PV display)
Setting n ame and
descript ion
Defau lt
val ue
Show s
only if
Symbol
Name
C1.SP
(C1.sp)
Control Set Point 1
Range Depending on PV
sensor type selected
100
-
A1.SP
(A1.sp)
Alarm Set Point 1
Range Depending on PV
sensor type selected
100
Output Type is
LIN(Linear)
A2.SP
(A2.sp)
Alarm Set Point 2
Range Depending on PV
sensor type selected
100
-
SOKT*
(sok.t)
Soak Run/stop
To Run/Stop Soak time
sto p
Soa k rat e
(s ok. r ) i s
not 0
AUTOTUNE P AR AME TERS
Parameter
(PV d isplay)
Setting Name & Description
Default
Value
Show if Only
Symbol
Name
A.TUN
(A.tun)
Auto Tune
Start / Stop Auto Tuning Process yes/no
0 : NO (Stop Auto Tuning)
1 : YES (Start Auto Tuning)
NO
Control Type(COP)
is PI or PID
PB
(pb)
Proportional
Band
Adjust Proportional Band
0 to 9999 or 0.0 to 999.9
10.0
Control Type(COP)
is P or PI or PID
TI
(ti)
Integral Time
Adjust Integral Time
0 to 1000
60
Control Type(COP)
is PI or PID
TD
(td)
Derivative Time
Adjust Derivative Time
0 to 180
0
Control Type(COP)
is PID
