Masimo Rad-5 User Manual

Rad-5/5v Chapter 2: Description
www.masimo.com 21 Masimo
17
Speaker
Provides audible indication of alarm conditions,
pulse tone and key-presses.
18
Pulse Tone Volume
Provides control of the pulse tone volume.
Cycles through three volume levels, and mute.
At the loudest level, pressing the Pulse Tone
Volume button will return the volume to mute.
19
Display Brightness
Provides control of the front panel indicator
brightness. Cycles through four brightness
levels. At the brightest level, pressing the
Display Brightness button will return the
display to the lowest brightness setting.
* Available on Rad-5 only.

Masimo Rad-5 Specifications

General

Type	Handheld Pulse Oximeter
SpO2 Range	0% to 100%
Pulse Rate Range	25 to 240 BPM
Perfusion Index Range	0.02% to 20%
Power Source	4 AA Alkaline Batteries
Operating Temperature	5°C to 40°C
Humidity	5% to 95% non-condensing
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
