Rad-5/5v Chapter 2: Description
www.masimo.com 20 Masimo
Displays functional arterial hemoglobin oxygen
saturation in units of SpO
2
. When searching for
saturation, it will flash dashed lines.
Displays the timing of the pulse. The height
indicates the quality of the signal.
Displays pulse rate in beats per minute (bpm).
When searching for a pulse, it will flash dashed
lines.
Used to enter the setup menus and to
select/activate certain entries within the
menu/setup system.
Used within the menu/setup system to move
through setup options. Not active during
patient monitoring.
Used to turn the unit on and off.
Indicates the status of batteries.
See Battery Level Indicator on page 26.
Illuminates when any alarm condition exists.
This indicator may not be turned-off or over-
ridden.
Displays the percentage of pulsatile signal to
non-pulsatile signal. Bar is highest when signal
quality is best.
MAX Sensitivity Indicator
On when MAX Sensitivity mode is enabled.
See Sensitivity (Rad-5) on page 29.
Displays current alarm silence status.
See Alarm Silenced Indicator on page 40.
Press to silence alarms.
See Alarm Silence on page 40.
During monitoring, use to adjust volume of the
pulse tone.
Within the menu/setup system, use to select
values within each menu option.
