3-4 MASTERFLEX
®
Digital Pump Drive Operating Manual Masterflex
Section 3
Operation
Main Screen
e drive has two different modes of operation—Continuous mode and
Copy Dispense mode. e drive also can be controlled directly via the
control panel or remotely through input signals to the 25-pin connector
on the back panel of the drive. Several primary control functions
including starting and stopping the pump, adjusting the rpm/flow rate,
and changing pump direction can be performed independently via use of
the control panel or through the remote control. is is true for both
Continuous and Copy Dispense modes (see the Remote Control section
following for more details).
CONTINUOUS MODE is the default pumping mode. e pump
will operate continuously at the set rpm (or flow rate) unless the drive is
either stopped or the flow rate/rpm is changed by the user. Refer to
Continuous Mode in this manual.
COPY DISPENSE MODE allows for dispensing at specific
volume intervals. (Example…repetitively filling vials with the same
volume by a single press of a button, foot switch or dispensing
wand.) Each dispense can be started either via the Enter Key
on the control panel or through the Start/Stop contact on the back
of the drive (see Remote Control section following). e Off Time feature
further allows for a continuous dispensing pattern by which a specific
off time interval between each dispense can be set. us a continuous
Dispense-Off Time-Dispense- Off Time cycle is created. An additional
feature of the Copy Dispense mode is Batch Count (0000/0015).
is allows
you to set a limit to the number of dispenses the pump will deliver before
stopping. Once the count limit is achieved, the batch count will have to be
reset to zero to continue pumping. Please note that batch count can be set
to infinity ( ) to allow for continuous dispense cycling. Refer to Copy
Dispense Mode in this manual.
SETTINGS Mode settings menu.
PUMP DIRECTION Select the direction of the pump flow. e
icon will rotate when the pump is running.
