Section 7 Specifications
Output
Speed: 0.1 to 300 rpm
Torque output, Maximum: 90 oz-in (6.5 kg•cm)
270 oz-in Starting
Speed regulation: Line ±0.1% F.S.
Load ±0.1% F.S.
Drift ±0.1% F.S.
Display: 128 x 64 LCD w/ LED Backlight
Remote outputs: Voltage speed output
(0–10V DC @ 1 k min)
Current speed output
(0–20 mA @ 0–600 )
Tach output
(1 to 3000 Hz, 50% duty cycle,
10 Hz/rpm)
Alarm, Local/Remote, Motor running output
(N.O. Relay, 1A @ 24V DC)
Input
Supply voltage limits: 24V DC
Current, max.: 1.3A
Remote Inputs: STOP/START, CW/CCW, PRIME
CURRENT/VOLTAGE ENABLE
(Contact closure)
Voltage input (0–10V DC @ 10 k ),
±50V common mode range
Current input
(0–20 mA or 4–20mA @ 250 ),
±50V common mode range
MASTERFLEX
®
Digital Pump Drive Operating Manual 7-1Masterflex
