MASTERFLEX
®
Digital Pump Drive Operating Manual 3-13Masterflex
Section 3
Operation
Section 3
Operation
Figure 3-9. Remote Control Menu Screens.
NAVIGATION: From the GLOBAL OPTIONS MENU select the
REMOTE CONTROL screen, shown above, and press ENTER.
VOLTAGE INPUT: is allows the user to input a voltage signal to
control the flow. Press ENTER on this screen to access the Voltage input
activation screen. By default the input is deactivated .
Using the UP and DOWN arrows on the control panel, highlight the
icon to activate, and press ENTER. A check mark will move next
to it.
Remote Control Menu
Remote Control
Voltage Input Menu
