102 Matrix SATATYA Devices Manual
Appearance Settings
Click on Appearance Settings option and the following page appears as shown below:
Display: Select the Display type from the drop-down list. The options available will depend on the device variant.
• Hue: Specify the hue value ranging between 0-100 by using the slider.
• Saturation: Specify the Saturation value ranging between 0-100 by using the slider.
• Brightness: Specify the Brightness value ranging between 0-100 by using the slider.
• Contrast: Specify the Contrast value ranging between 0-100 by using the slider.
Click on Save to save the settings.
Layout Style: This field contain a particular layout format (of monitoring windows) from the total predefined layout
templates.The user also can define upto 5 layout styles.
In Local client, User will get the default layout styles already stored according to the SATATYA device variant
shown below.
Default: It is also possible to set the configured layout style as default layout for Main and Spot output display by
enabling the Default checkbox against the layout style.
Auto Page Navigation
This option enables the user to start and stop viewing the cameras in a sequential pattern depending on the layout
template selected for displaying the live video of the cameras.
Layout Style/ SATATYA devices Style 1 Style 2 Style 3 Style 4 Style 5
All HVR & NVR Variants except NVR 64 4 x 4 2 x 2 3 x 3 1 x 1 1 + 5
NVR 64 2 x 2 1 x 1 2 x 2 1 x 1 2 x 2
NVRX variants 4 x 4 1 x 1 2 x 2 3 x 3 5 x 5
