132 Matrix SATATYA Devices Manual
As per the number of cameras selected for playback, the display mode will be changed. i.e 1x1, 2x2, 3x3 or 4x4
You can change the display mode from the Display Mode option.
The horizontal line showing the recording (length) of selected camera assigned in a particular window. This will be
displayed in the time line as shown below:
Hours: The user can view the finer details of recording by zooming into 1 hour or can be zoomed out to view the
overall recordings of the day i.e 24 hours. The Time line will change according to the hours selection.
Select the time format from the options:
• 24 hours
• 12 hours
• 6 hours
• 1 hour
These different types of recording will be shown with different colors in Time-line where, Alarm has the highest
priority and Schedule has the least priority.
For E.g: If there are all types of recordings are available in one minute, then only Alarm Recording will be shown as
it has highest priority.
In case, Manual, Cosec and Schedule Recordings are available, then Cosec recording, being at the highest priority,
will be displayed.
At a time only one recording type will be displayed as per the priority for selected camera.
For the description on Playback control buttons, See “Playback Toolbar” on page 144.
To Start Playback: After specifying the date, Cameras, Hours and Event type, take the slider in Timeline to the
position from where the playback is to be started.
