Matrix
36
SIMADO GFX11 System Manual
Where,
N is the call type of the programming command issued.
XX is
Value Meaning
IC Incoming Call
OC Outgoing Call
RC Received Calls
DC Dialed Calls
AC All Calls
DUR-Duration
HH-Hours is from 00 to 99.
MM-Minutes in 24 hours format from 00 to 59.
SS-Seconds in 24 hours format from 00 to 59.
Duration is reset to 00:00:00 if the total duration exceeds
99:59:59.
• In case of last call duration display, XX will have either IC or OC
thus enabling to determine whether the last call was incoming or
outgoing.
• Above configuration works only if FSK CLI is set on the FXS port.
But, if DTMF CLI is set on the FXS port, display will be as shown
below (only numbers):
N HH MM SS
Relevant Topics:
1.
Programming the System through FXS Port 68
2.
System Security (Passwords) 80
=X=X=
