SIMADO GFX11 System Manual
41
Programming Tone
This tone is given in the system programming mode when the
SIMADO GFX11 is waiting for a new command from the user. This
tone remains till the user dials the first digit of a new command.
Confirmation Tone
This tone is given as continuous, fast beeps to indicate that the
SIMADO GFX11 has successfully executed a feature command/
programming command issued by the user. This is also called the
Programming Confirmation Tone. This tone remains for 3 seconds in
the programming mode and in the feature access mode it remains
till the user goes ON-Hook.
How it works?
• Different country follows different standard of frequency and
cadence of the tones, known as ‘Tone Type’.
• This Matrix product supports 33 tone types for 33 countries in all.
• Refer the table at the end of chapter for the details on cadence
data for different country.
• Just program code for the tone type, to select the country
specific tones.
How to program?
By programming ‘Code’, the GFX11 supports Call Progress Tone for
that country, where it is installed.
Use the following command to select the country for tone type:
104-Code-#*
Where,
Freq. Cadence Freq. Cadence Freq. Cadence
Hz second Hz second Hz second
01 Australia 425*25 cont. 425 0.375on 0.375off 425 0.375on 0.375off
02 Argentina 425 cont. 425 0.3on 0.2off 425 0.3on 0.4off
03 Belgium 425 cont. 425 0.5on 0.5off 425 0.167on 0.167off
04 Brazil 425 cont. 425 0.25on 0.25off 425 0.25on 0.25 off
05 China 450 cont 450 0.35 on 0.36off 450 0.7on 0.7off
06 Egypt 425*50 cont 425*50 1.0on 4.0off 450 0.5on 0.5off
07 France 440 cont 440 0.5on 0.5off 440 0.25on 0.25off
08 Germany 425 cont 425 0.48on 0.48off 425 0.24on 0.24off
09 Greece 425
0.2on 0.3off
0.7on 0.8off
425 0.3on 0.3off 425 0.15on 0.15off
Dial Tone
CountryCode
Error ToneBusy Tone
