SIMADO GFX11 System Manual
43
Calling Line Identification and Presentation (CLIP)
What’s this?
The SIMADO GFX11 provides the facility to detect the calling party
number and present it to the FXS port. This is called Calling Line
Identification and Presentation. The calling party number is
displayed on LCD of the telephone instrument.
The FXS port of the SIMADO GFX11 supports two CLI protocols viz.
DTMF and FSK. Hence telephone instrument-supporting DTMF
signalling or FSK signalling can be interfaced with the SIMADO
GFX11.
How it works?
The SIMADO GFX11 senses the CLI received from the network and
sends this information to the FXS port along with the ringing signal.
The FXS port supports any of the 3 types of signalling viz. DTMF
signalling, ITU-T V.23 FSK and Bellcore FSK. Depending on the
telephone instrument type the FXS port should be programmed.
How to program?
Program the signalling type of the FXS port. Please refer to ‘
FXS
Port Parameters’ for more details.
Relevant Topics:
1.
Calling Line Identification Restriction (CLIR) 44
2.
FXS Port Parameters 53
