SIMADO GFX11 System Manual
53
FXS Port Parameters
What’s this?
• The SIMADO GFX11 offers the flexibility to program the Inter Digit
Wait Timer and the CLI type for the FXS port. Few parameters
are programmed to get the expected functions from the system,
as explained below:
• CLI type
The FXS port supports the following three types of CLI signalling:
• DTMF.
• ITU-T V.23 FSK.
• Bellcore FSK.
• Replacing ‘+’ by digits in CLI:
• Matrix GFX11 supports to replace ‘+’ of the CLI number, with
some other digits. Normally it is the prefix for international dialing.
• On receipt of call on Mobile port, if the first digit in CLI is ‘+’, it
is replaced with the programmable digits and is presented on
the FXS port.
• If first digit is not ‘+’, the same CLI is presented on the FXS port.
• Maximum of four digits can be replaced with ‘+’.
Example:
• On receipt of call on GSM port, if calling party number provided
by network is +91 265 2630555, system will eliminate the string
‘+’ and an International dialing prefix (‘00’ if used in India) which is
programmed, will be added in the number string so that the
number can be processed by the network.
How to program?
Step 1: Program CLI type using command 222.
Step 2: Program the digit which will be replaced with ‘+’ in CLI
using command 301.
Step 3: Program inter digit wait timer using command 226.
Step 1
Use following command to program the CLI type for the FXS port:
222-CLI Type-#*
Where,
