Matrix simado gfx11 System Manual

Matrix
52
SIMADO GFX11 System Manual
The default, emergency number table programmed in the system
looks as shown below:
Index Emergency Number
1 112
2 911
3Null
4Null
Example:
Suppose an emergency number 999 and 110 is required to be dialed
out then program the table using commands:
151-1-999-#* (Program Emergency Number 999)
151-2-110-#* (Program Emergency Number 110)
Important Points:
• The GSM port from where, the emergency number is to, be dialed
should be enabled, even if it is ‘False’.
• The number programmed, which are to be dialed through GSM
port as emergency number should exist as emergency number
either in the GSM module or in the SIM in the memory storage,
which is classified as emergency number. For this information,
contact your GSM Service Provider.
Relevant Topic:
1.
GSM Port Parameters 55
=X=X=

Matrix simado gfx11 Specifications

General

Brand	Matrix
Model	simado gfx11
Category	Gateway
Language	English
