Inspecting the Matrox Solios eV-CL package 19
Inspecting the Matrox Solios eV-CL package
You should check the contents of your Matrox Solios eV-CL package when you
first open it. If something is missing or damaged, contact your Matrox
representative.
Standard items
You should receive the following:
• The Matrox Solios eV-CLB, eV-CLBL, eV-CLF, or eV-CLFL board, depending
on which was purchased
• Depending on the board purchased, you will receive a different alternative cable
adapter bracket to access the signals of the internal auxiliary I/O connectors from
outside the computer enclosure.
- With the Matrox Solios eV-CLB and Matrox Solios eV-CLF you should receive
a cable adapter bracket with one DBHD-15 connector.
- With the Matrox Solios eV-CLBL and Matrox Solios eV-CLFL you should
receive a cable adapter bracket with either two DBHD-15 connectors or one
DBHD-44 and one DB-9 connectors, depending on which cable adapter
bracket you chose.
