108 Appendix B: Technical information
Internal 32-pin auxiliary I/O connector
The internal 32-pin auxiliary I/O connector on the Matrox Solios eV-CLBL and
Matrox Solios eV-CLFL board is a 0.1" spacing, 32-pin male connector. This
connector is to be connected to the dual DBHD-15 connector’s flat ribbon cable.
You can use the connector to transmit/receive auxiliary signals for the two
acquisition paths. The connector is located close to the top edge of the board,
making the auxiliary signals accessible from inside the computer enclosure.
1
2
31
