Matrox Solios eV-CL acquisition section
Matrox Solios eV-CL can capture video from digital video sources compliant with
the Camera Link specification. Matrox Solios eV-CLB and eV-CLBL can provide
power over Camera Link (PoCL) to attached video sources.
Matrox Solios eV-CL supports monochrome, RGB color, and Bayer
color-encoded acquisition. Matrox Solios eV-CLB and eV-CLBL can decode the
color information of Bayer color-encoded images; whereas, Matrox Solios eV-CLF
and eV-CLFL can only transfer the images to the Host for decoding. Besides
standard Camera Link video sources, Matrox Solios eV-CL supports additional
types of video sources, including time-multiplexed video sources.
Using the color space converter of the video formatter, grabbed data can be
converted to RGB24, RGB32, or YUV16 format. In addition, data can be
converted to 8-bit, 10-bit, 12-bit, 14-bit, and 16-bit monochrome data.
Matrox Solios eV-CLB and eV-CLBL in dual-Base configuration have two
independent acquisition paths. Matrox Solios eV-CLB and eV-CLBL, in
single-Medium configuration, and Matrox Solios eV-CLF and eV-CLFL have one
acquisition path.
Each ac quis ition p ath can grab up to 85 Mega-samples/sec.
*
Each acquisition path
has its own programmable synchronization generator (PSG), LUTs, and
formatters, and can have a different acquisition rate.
Matrox Solios eV-CL supports a comprehensive set of general purpose I/O signals
and serial ports to control cameras and other video sources.
*. Note that when using a 10 tap 8-bit video source, the maximum Camera Link fre-
quency is 70 Mega-samples/sec when grabbing to Host and 80 Mega-samples/sec
when grabbing on-board
.
