11MAXDATA Server PLATINUM 3200 I M7
2 Chassis Description
Feature Summary
Table 3. Feature Summary
Feature P3200 I Description
Peripheral Bays 3 multi-mount 5.25 peripheral bays
Drive Bays (6 + 4) bay
layout
One fixed drive bay for up to 6 hard drives
Optional: Hot swap drive bay
• for 6 hard drives (SAS/SATA)
• for 4 hard drives (SAS/SATA)
• P3200 I Base: up to 6 drives
P3200 I Redundant: up to 10 drives
Expansion Slots Six full-length PCI expansion slots are available.
Form Factor 5U Tower, convertible to rack mount
Power Delivery a) P3200 I Base: One fixed 670-W power supply with an integrated fan
b) P3200 I Redundant Power: Two highly efficient, redundant 750-W
hot swap power supplies with an integrated fan
Cooling a) P3200 I Base: Three fixed, non-redundant chassis fans
• Two 120-mm fans: one at the front and one at the rear
• One 92-mm fan at the front
b) P3200 I Redundant: Four hot-swap, redundant chassis fans:
• Two 120 mm and two 92 mm fans at the front
