28 Server Board Features
Callout LED Function
F.
G.
H.
I.
J.
K.
M.
N.
O.
P.
Q.
R.
DIMM C1 fault LED
DIMM C2 fault LED
DIMM B1 fault LED
DIMM B2 fault LED
DIMM A1 fault LED
DIMM A2 fault LED
DIMM D2 fault LED
DIMM D1 fault LED
DIMM E2 fault LED
DIMM E1 fault LED
DIMM F2 fault LED
DIMM F1 fault LED
These LEDs indicate a fault has occurred with the DIMM in-
stalled in the corresponding socket. Replace the faulty DIMM.
S. +5-volt standby LED This LED is green whenever AC power is applied to the
system. The system does not need to be powered on in order
for this LED to be on.
RAID Support
The options for hard drive configuration are located in the BIOS Setup under “Advanced” > “Mass
Storage Controller Configuration”.
The option “On-board SATA Controller” is enabled as default and allows the following additional
“SATA Mode” options:
• “Enhanced” – supports up to six SATA devices in Native IDE mode.
• “Compatibility” – supports up to four SATA ports [0/1/2/3] in Legacy IDE mode and two SATA
ports [4/5] in Native IDE mode.
• “AHCI” – supports all SATA ports in Advanced Host Controller Interface mode.
• “SW RAID” – switches on Intel
®
Embedded Server RAID Technology II mode with support for
RAID 0, 1 and 10.
Hardware Requirements
Processor
One or two Intel
®
Xeon
®
5500 processors must be installed.
System memory
The server board provides six memory channels, each with two slots. Channels A to C with DIMM A1,
A2, B1, B2, C1 and C2 are assigned to processor 1. Channels D to F with DIMM D1, D2, E1, E2, F1 and
F2 are assigned to processor 2. Channels D, E and F can only be used if processor 2 is populated.
If two processors are populated, then they can both access the entire memory via Intel
®
QuickPath
Interconnect (Intel
®
QPI).
Within a channel, DIMM 1 must be populated before DIMM 2 can be used.
CPU socket 1 CPU socket 2
Channel A Channel B Channel C Channel D Channel E Channel F
A1 A2 B1 B2 C1 C2 D1 D2 E1 E2 F1 F2
