MAXDATA PLATINUM 3200 I - Chassis Rear View; Peripherals; 5-Inch Half­height Peripheral Bays

14 Chassis Description
Chassis Rear View
Figure 5. MAXDATA PLATINUM 3200 I Base – Chassis Rear View
A. Power supply
B. I/O Ports
C. Expansion Slot Covers
D. PCI Card Latch
E. Rear Serial B Connector (optional)
F. AC Power Connector
Peripherals
5.25-inch Halfheight Peripheral Bays
The upper bays of the server chassis are designed for removable media peripherals. Three 5.25-inch,
half-height drive bays are available for floppy, CD-ROM or tape drives.
 NOTE
One multi-purpose 5.25-inch drive carrier is included with the chassis. This drive carrier can hold either
a 3.5 inch drive (by removing the knockout) or a fixed drive.
C
E
D
F
B
A
