23MAXDATA Server PLATINUM 3200 I M7
4 Server Board Features
This chapter briefly describes the main features of the PLATINUM 3200 I Server Board. It provides
a list of the server board features and diagrams showing the location of important components and
connections on the server board.
Table 4. Server Board Features
Feature Description
Server board Intel
®
S5520HC
Processor One or two Intel
®
Xeon
®
5500 processors with a thermal design power (TDP)
of up to 95 W
System memory • 12 DIMM slots, 6 per processor, distributed over three memory channels
• Up to 96 GB system memory
• 800/1066/1333 MT/s ECC registered (RDIMM) or unbuffered (UDIMM)
DDR3 memory
• No mixing of RDIMMs and UDIMMs
Chipset • Intel
®
5520 Chipset IOH
• Intel
®
82801Jx I/O Controller Hub (ICH10R)
Peripheral interfaces External connections:
• One DB-15 graphics port
• One serial DB9 port A
• Two RJ45 network ports for 10/100/1000 Mbps
• Four USB 2.0 ports (back panel)
Internal connections:
• Two USB connectors for each of the two USB 2.0 ports (2 leading to the
front)
• One type A USB 2.0 port
• One DH10 connector for serial B port
• Six SATA II ports
• One port for an optional SAS/SAS ROMB module
• One port for an optional remote management module 3
Graphics On-board ServerEngines LLC Pilot II controller with integrated 2D video
controller, 64 MB DDR2 memory, 8 MB of which is graphics memory
LAN One Intel
®
82575EB controller with two ports for 10/100/1000 Mbps Ethernet
LAN
Add-in card slots • One PCI-E 2.0 x16 slot (x8 connection)
• Three PCI-E 2.0 x8 slots
• One PCI-E 1.1 x8 slot (with a split SAS module socket x4 connection)
• One 5 V 32-bit / 33 MHz PCI slot
Server management • An integrated IPMI 2.0-compliant baseboard management controller
• Support for remote management module 3 (“KVM over IP”)
• Support for system management software
• Light-Guided Diagnostics on replaceable units (FRUs)
