BITFIELD BITS DESCRIPTION DECODE
AGCMODE 12:11 AGC mode control
0x0: Independent I and Q
0x1: Reserved
0x2: Gain set by programming of GAININ bits
0x3: Reserved
FORMAT 10:9 Output data format
0x0: Unsigned binary
0x1: Sign and magnitude
0x2: Two's complement binary
0x3: Two's complement binary
BITS 8:6 Number of bits in the ADC
0x0: 1 bit
0x1: Reserved
0x2: 2 bits
0x3: Reserved
0x4: 3 bits
0x5: Reserved
0x6: Reserved
0x7: Reserved
DRVCFG 5:4 output driver conguration
0x0: CMOS logic
0x1: Reserved
0x2: Analog outputs (ADC bypass mode)
0x3: Analog outputs (ADC bypass mode)
RESERVED 3 Reserved: DO NOT CHANGE VALUE RESERVED
RESERVED 2 Reserved: DO NOT CHANGE VALUE RESERVED
DIEID 1:0 Identies version of IC
Conguration 2 (0x1) (continued)
