PLL Integer Division Ratio (0x4)
PLL main and reference division ratios, other controls
BIT 31 30 29 28 27 26 25 24
Field RESERVED[3:0] NDIV[14:11]
Reset 0x0 1536
Access Type Write, Read Write, Read
BIT 23 22 21 20 19 18 17 16
Field NDIV[10:3]
Reset 1536
Access Type Write, Read
BIT 15 14 13 12 11 10 9 8
Field NDIV[2:0] RDIV[9:5]
Reset 1536 16
Access Type Write, Read Write, Read
BIT 7 6 5 4 3 2 1 0
Field RDIV[4:0] RESERVED[2:0]
Reset 16 0x0
Access Type Write, Read Write, Read
BITFIELD BITS DESCRIPTION DECODE
RESERVED 31:28 Reserved: DO NOT CHANGE VALUE RESERVED
NDIV 27:13 PLL integer division ratio
RDIV 12:3 PLL reference division ratio
RESERVED 2:0 Reserved: DO NOT CHANGE VALUE RESERVED
www.maximintegrated.com
Maxim Integrated
39
MAX2771 Multiband Universal GNSS Receiver
