Maxim Integrated MAX2771 - Test Mode 2 (0 X9)

Test Mode 2 (0x9)
RESERVED
BIT 31 30 29 28 27 26 25 24
Field RESERVED RESERVED RD_CALC RESERVED[3:0]
RE
SERVED[2]
Reset 0x0 0x0 0x0 0x0 0x0
Access Type Write Only Write, Read Write, Read Write, Read Write, Read
BIT 23 22 21 20 19 18 17 16
Field RESERVED[1:0] RESERVED RESERVED RESERVED[1:0] RESERVED RESERVED
Reset 0x0 0x0 0x0 0x0 0x0 0x0
Access Type Write, Read Write, Read Write, Read Write, Read Write, Read Write, Read
BIT 15 14 13 12 11 10 9 8
Field RESERVED RESERVED RESERVED RESERVED[4:0]
Reset 0x0 0x0 0x0 0x00
Access Type Write, Read Write, Read Write, Read Write, Read, Dual
BIT 7 6 5 4 3 2 1 0
Field RESERVED[4:0] RESERVED RESERVED RESERVED
Reset 0x00 0x0 0x1 0x0
Access Type Write, Read, Dual Write, Read Write, Read Write, Read
BITFIELD BITS DESCRIPTION DECODE
RESERVED 31 Reserved: DO NOT CHANGE VALUE RESERVED
RESERVED 30 Reserved: DO NOT CHANGE VALUE RESERVED
RD_CALC 29 Reserved: DO NOT CHANGE VALUE RESERVED
RESERVED 28:25 Reserved: DO NOT CHANGE VALUE RESERVED
RESERVED 24:22 Reserved: Write 011 to this biteld. RESERVED
RESERVED 21 Reserved: DO NOT CHANGE VALUE RESERVED
RESERVED 20 Reserved: DO NOT CHANGE VALUE RESERVED
RESERVED 19:18 Reserved: DO NOT CHANGE VALUE RESERVED
RESERVED 17 Reserved: DO NOT CHANGE VALUE RESERVED
RESERVED 16 Reserved: DO NOT CHANGE VALUE RESERVED
RESERVED 15 Reserved: DO NOT CHANGE VALUE RESERVED
RESERVED 14 Reserved: DO NOT CHANGE VALUE RESERVED
RESERVED 13 Reserved: DO NOT CHANGE VALUE RESERVED
RESERVED 12:8 Reserved: DO NOT CHANGE VALUE RESERVED
RESERVED 7:3 Reserved: DO NOT CHANGE VALUE RESERVED
RESERVED 2 Reserved: DO NOT CHANGE VALUE RESERVED
RESERVED 1 Reserved: DO NOT CHANGE VALUE RESERVED
RESERVED 0 Reserved: DO NOT CHANGE VALUE RESERVED
www.maximintegrated.com
Maxim Integrated │ 44
MAX2771 Multiband Universal GNSS Receiver
