Maxim Integrated MAX2771 - PLL Fractional Division Ratio (0 X5)

PLL Fractional Division Ratio (0x5)
PLL fractional division ratio, other controls
BIT 31 30 29 28 27 26 25 24
Field RESERVED[3:0] FDIV[19:16]
Reset 0x0 0x80000
Access Type Write, Read, Dual Write, Read
BIT 23 22 21 20 19 18 17 16
Field FDIV[15:8]
Reset 0x80000
Access Type Write, Read
BIT 15 14 13 12 11 10 9 8
Field FDIV[7:0]
Reset 0x80000
Access Type Write, Read
BIT 7 6 5 4 3 2 1 0
Field RESERVED[3:0] RESERVED RESERVED RESERVED RESERVED
Reset 0x7 0x0 0x0 0x0 0x0
Access Type Write, Read, Dual Write, Read Write, Read Write, Read Write, Read
BITFIELD BITS DESCRIPTION DECODE
RESERVED 31:28 Reserved: DO NOT CHANGE VALUE RESERVED
FDIV 27:8 PLL fractional division ratio
RESERVED 7:4 Reserved: DO NOT CHANGE VALUE RESERVED
RESERVED 3 Reserved: DO NOT CHANGE VALUE RESERVED
RESERVED 2 Reserved: DO NOT CHANGE VALUE RESERVED
RESERVED 1 Reserved: DO NOT CHANGE VALUE RESERVED
RESERVED 0 Reserved: DO NOT CHANGE VALUE RESERVED
