Maxim Integrated MAX2771 - External Component List; Ordering Information; Table 16. External Component List

PART NUMBER TEMP RANGE PIN-PACKAGE
MAX2771ETI+ -40°C to +85°C 28 TQFN-EP*
DESIGNATION QUANTITY DESCRIPTION
C0, C11 2 0.47nF AC-coupling capacitors
C5 1 0.75nF PLL loop lter capacitor
C6 1 15pF PLL loop lter capacitor
C4, C7, C8, C9, C10, C13 6 0.1μF supply voltage bypass capacitor
C2, C3 2 10nF AC-coupling capacitor
C1, C12 2 0.47nF AC-coupling capacitor
C14 1 0.1nF supply voltage bypass capacitor
R0 1 15kΩ PLL loop lter resistor
L0 1 5.6 nH RF matching inductor for high-band LNA inputs
L1 1 8.4 nH RF matching inductor for low-band LNA input
C15 1 1.7 pF RF matching capacitor for high-band LNA input
C16 1 1.1 pF RF matching capacitor for low-band LNA input
Table 16. External Component List
+Denotes a lead(Pb)-free/RoHS-compliant package.
*EP = Exposed pad.
Ordering Information
www.maximintegrated.com
Maxim Integrated │ 49
MAX2771 Multiband Universal GNSS Receiver
