McHale Fusion Vario Baler & Wrapper
136
15. Once the rear cradle is raised to the home position the side-tip is automatically
swung into the vertical transport position, allowing it to be transported safely, as
shown below. Finally an additional linch pin must be installed, as shown, to
secure the gravity latch in position.
WARNING: It is very important that this linch pin is removed before lowering the
rear cradle again, otherwise the side-tip components are put under undue strain!
