19
Front Panel Controls, Sensor and Headphone Jack
Selects the Trim Func-
tion for making audio
and front panel display
adjustments
IR (Infra Red) Sensor ac-
cepts IR signals directly
from the MHT100 Remote
Control
Selects which of the seven Audio/
Video Sources or Tuner Signal is
available at the Zone A and B Audio
Outputs, Component Video for Zone
A, MON ZONE A and MON ZONE
B Video Outputs, and available for
VCR Outputs
Adjusts the Listen
volume level of all
eight channels for
Zone A and both
channels for Zone B
Selects the desired audio
operating mode and selects
the external eight channel
input
Low Impedance Dynamic
Headphones can be connected
for two channel listening and
the Zone A Loudspeakers are
automatically muted when the
headphone plug is inserted
To Next Page
