38
SETUP, con’t
Figure 27
MENU: SYSTEM SETUP
1. VIDEO NTSC
2. TUNER USA
3. TEMP DISPLAY Full
EXIT
How to change System Setup
The MHT100 is marketed all over the world. The SYS-
TEM SETUP allows for selection of the proper Video For-
mat Standard for the On-Screen Displays. If the AM/FM
Tuner Module is installed there are also selections to match
the Tuner Functioning with the Radio Broadcasts in your
country. There are two different types of On-Screen Dis-
plays.
1. Press and hold the front panel Setup Push-button ap-
proximately three seconds to enter the Setup Mode.
The word SETUP will appear on the MHT100 Front
Panel Display and the MAIN SYSTEM SETUP Menu
will appear on the Monitor/TV screen. Refer to figure
12 on page 25.
2. Using the Up or Down directional push-buttons
select Number 8 System Settings on the On-Screen
Menu, followed by the SELECT Push-button on the
Remote Control. Refer to figure 27.
Video
3. Using the Up or Down directional push-buttons
select Number 1 VIDEO from the On-Screen Menu,
followed by pressing Left or Right directional
push-buttons to select either NTSC or PAL Video For-
mat.
Note: If the TV/Monitor stops displaying the On-Screen
Setup properly, just press the Left or Right
directional push-button a second time.
Tuner
4. The On-Screen Menu Item Number 2 indicates the
countries the TM1 AM/FM Tuner Module is set for.
Temp Display
5. Using the Up or Down directional push-buttons
select Number 3 TEMP DISPLAY from the On-Screen
Menu, followed by pressing Left or Right direc-
tional push-buttons to select either OFF, SIMPLE or
FULL On-SCREEN Display Information. The
SIMPLE On-SCREEN Display Information will in-
clude Zone A Input Selection and Volume.
The FULL On-SCREEN Display Information will in-
clude the SIMPLE Display Information for Zone A
plus additional Audio/Video Input Information. Select
EXIT on the menu and the MAIN SYSTEM SETUP
Menu will reappear on the Monitor/TV screen.
6. Select EXIT from the MAIN SYSTEM SETUP Menu.
If you are satisfied with the changes that you may have
made, select YES to save those changes or NO not to
save them. The MHT100 will then return to normal op-
eration. Refer to figure 13 on page 25.
Adjustment North America Other Country New Setting
Video NTSC
Tuner USA
Temp Display Full Full
System Setup
Defa ult Settings
