Power Amplifer and General Specifications
General Specifications
Power Requirements
100 Volts, 50/60Hz at 8.4 Amps
110 Volts, 50/60Hz at 7.7 Amps
120 Volts, 50/60Hz at 7.0 Amps
220 Volts, 50/60Hz at 3.5 Amps
230 Volts, 50/60Hz at 3.5 Amps
240 Volts, 50/60Hz at 3.5 Amps
NOTE: Refer to the rear panel of the MHT100 for the correct
voltage.
Dimensions
Front Panel: 17-3/4 inches (45.09cm) wide, 9-7/16 inches
(23.97cm) high. Depth behind front mounting panel is 19
inches (48.26cm) including clearance for connectors. Panel
clearance required in front of mounting panel is 1-1/8
inches (2.9cm).
Weight
73 pounds (160.9Kg) net, 87 pounds (191.8Kg) shipping
Power Output
Minimum sine wave continuous average power output per
channel, all channels operating is:
100 watts into a 4 ohm load
70 watts into a 8 ohm load
Rated Power Band
20Hz to 20,000Hz
Total Harmonic Distortion
Maximum Total Harmonic Distortion at any power
level from 250 milliwatts to rated power output is:
0.05% for 4 or 8 ohm load
Dynamic Headroom
1.8dB
Frequency Response
+0, -0.25dB from 20Hz to 20,000Hz
+0, -3dB from 10Hz to 100,000Hz
Sensitivity
1.0 Volt
A-Weighted Signal To Noise Ratio
92dB (112dB below rated output)
Intermodulation Distortion
Maximum Intermodulation Distortion if instanta-
neous peak output per channel does not exceed
twice the rated output, for any combination of fre-
quencies from 20Hz to 20,000Hz, with all channels
operating is:
0.05% for 4 or 8 ohm loads
Input Impedance
20,000 ohms
Wide Band Damping Factor
100 at 4 ohms
200 at 8 ohms
Power Amplifer Specifications
