"2033ES / 2633ES" Service & Parts Manual - ANSI Specifications October 2008
Page 2-11
Limit Switch
There is a limit switch to prevent driving in high speed.
When the platform is raised above approximately 7 feet
(2.3 meters), the machine will be in the slow speed
mode.
Pothole Switch
When the platform is elevated above ___feet, the
pothole switch activators raise, activating the two (2)
pothole switches and causing the pothole bars to
extend.
When the platform is lowered, the pothole switch acti-
vators lower, depressing the two (2) switches and
causing the pothole bars to retract.
ART_2179
Pothole
Switches
Motion Light
Limit Switch
