Page 10 93808 – October 2014
6092RT Component Locations
Modules
ART_3026
Entry ladders not shown for clarity.
Hydraulic
Tank
Sight Gauge
Sight
Gauge
Fuel Tank
Hydraulic
Valve
Blocks
Battery
Base Controls
Fuel/Fluid
Module
Control
Module
Battery Disconnect
(inside)
