Mec SE Series - Motor Controller Assembly, 1930 SE

March 2017
Page A-35
“SE Series” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Motor Controller Assembly -- 1930SE
ITEM PART NO. QTY DESCRIPTION
-- 41821 -- Motor Controller Assembly, 1930SE
1 53014 2 Nut M8
2 53055 2 Washer, M8 Spring
3 50001 2 Washer M8
4 41827 1 Fuse, 250A
5 53061 2 Screw M4×16-H
6 41092 1 Fuse Holder
7 41828 1 Plate
8
41095
1 DC Contactor
9 50284 4 Washer 4
10 53062 4 Washer, M4
11 50483 2 Screw, M4 x 10-H
12 41610 1 Motor Controller
13 50047 1 Nut, M6
14 50445 1 Bolt, M6 x 16
15 41586 1 Fuse, 350A
16 53051 4 Screw, M6 x 16
17 53046 6 Washer, M6 Spring
18 50000 7 Washer, M6
