Mec SE Series - Battery Module Assembly - 2632 SE, 3346 SE, 4046 SE, 4555 SE

March 2017
Page A-25
“SE Series” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Battery Module Assembly -- 2632SE, 3346SE, 4046SE, 4555SE
ITEM PART NO. QTY DESCRIPTION
1 53058 4 Screw M6×12-H
2 50000 6 Washer M6
3 53046 6 Washer, M6 Spring
4 41069 1 Battery Charger
5 50049 1 Nut, M10
6 50002 1 Washer, M10
7 50001 2 Washer 8
8 53055 2 Washer, M8 Spring
9 50048 2 Nut M8
10 41060 2 Hinge Pin
11 41046 4 Bearing
12 41019 2 Bearing
13 41061 2 Snap Ring
14 50507 1 Bolt, SHCS M10 x 60
15 41062 1 Rubber Block
16
41403 4 2632SE -- Battery
41404 4 3346SE -- Battery
41405 4 4046SE, 4555SE -- Battery
17
41585 1 2632SE, 3346SE -- Battery Module Weldment
41816 1 4046SE -- Battery Module Weldment
41063 1 4555SE -- Battery Module Weldment
18 41065 1 Main Power Switch
19
41408 1 2632SE, 3346SE -- Brace
41066 4046SE, 4555SE -- Brace
20 41067 1 Latch
21 50117 2 Screw M6×25
22 41068 1 Handle Ring
23 53042 4 Screw M5×16
24 41575 1 Plug Receptacle
25 53034 4 Screw, M4 x 12-H
Trojan T105
Trojan T125
Trojan T1275
