Mec SE Series - Rear Wheel Assembly - 2632 SE, 3346 SE, 4046 SE, 4555 SE

March 2017
Page A-17
“SE Series” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Rear Wheel Assembly -- 2632SE, 3346SE, 4046SE, 4555SE
ITEM PART NO. QTY DESCRIPTION
-- 41441 2 Rear Wheel Assembly
1 41021 1 Cushion
2 41022 1 Axle Seat
3 41023 1 Seal FB70 50 8
4 41324 1 Bearing 30206
5 41322 1 Cotter Pin 5×40
6 41025 1 Bearing seat
7 41328 1 End cover
8 41027 1 Wheel
9 53053 5 Washer, M12 Spring
10 53052 5 Bolt M12-1.5 x 45
11 50003 9 Washer 12
12 50457 6 Screw M8×20
13 41028 1 Nut M22×1.5
14 41304 1 Washer
15 41324 1 Bearing
16 50323 4 Bolt M12×100
17 50590 4 Nut M12
