Mec SE Series - Steering Wheel Assembly - 2632 SE, 3346 SE, 4046 SE, 4555 SE

March 2017
Page A-13
“SE Series” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Steering Wheel Assembly -- 2632SE, 3346SE, 4046SE, 4555SE
ITEM PART NO. QTY DESCRIPTION
1
41391 1 2632SE -- Steer linkage
41393 1 3346SE, 4046SE -- Steer linkage
41394 1 4555SE -- Steer linkage
2 50214 1 Bolt M6×30
3 41342 1 Pin 6×45
4 50000 1 Washer 6
5 50047 1 Nut M6
6 41386 1 Axle
7 41387 1 Steering cylinder
-- 41388 1 Seal kit
8 41389 1 Axle
9 53044 2 Screw M5×10
10 41010 2 Cover
11 41011 4 Bearing
12 41061 1 Snap Ring
13 41378 2 Washer
14
41014 2 Sheath
15 41380 2 Drive Motor
-- 41381 2 Reducer
-- 41382 2 Motor
-- 41383 2 Brake
16 53052 10 Bolt M12×1.5×45
17 53053 10 Washer, M12 Spring
18 50003 10 Washer, M12
19 41384 2 Wheel
20 41385 1 Steer yoke
21 50002 12 Washer, M10
22 53054 12 Washer, M10 Spring
23 50590 2 Nut M12
24 53060 12 Bolt 3/8-16×1.51-C
25 41376 2 Screw
26 41377 1 Steer yoke
27 41019 2 Bearing
28 41020 2 Bearing
29 50215 2 Bolt M10×20
