Mec SE Series - Control Module Assembly - 2632 SE, 3346 SE, 4046 SE, 4555 SE

March 2017
Page A-29
“SE Series” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Control Module Assembly -- 2632SE, 3346SE, 4046SE, 4555SE
ITEM PART NO. QTY DESCRIPTION
1 41061 2 Snap Ring
2 41019 2 Bearing
3 41046 4 Bearing
4 41060 2 Hinge Pin
5 50025 2 Bolt M6×20
6 53046 4 Washer M6, Spring
7 50000 6 Washer M6
8 41070 1 Hour Meter
9 41071 1 Hydraulic Tank Assembly
10 53014 10 Nut M8
11 50001 14 Washer 8
12 53051 2 Screw M6×16-H
13
41409 1 2632SE, 3346SE, 4046SE -- Controls Module Weldment
41822 1 4555SE -- Controls Module Weldment
14 41068 1 Handle Ring
15 50117 2 Bolt M6×25
16
428
96 1 Latch
17
41093
1
Mo
tor Controller
18 41073 1 Cover
19 50031 6 Bolt M8×25
20 41074 1 Alarm
21 41075 1 Horn
22 53058 2 Screw M6×12-H
23 50031 4 Screw M8×25
24 53059 4 Screw M8×16
25 50295 4 Bolt M8×16
26 53055 8 Washer M8, Spring
27 41410 1 Motor Bracket
28
41411 1 2632SE -- Motor
41076 1 3346SE, 4046SE, 4555SE -- Motor
29 41077 1 Oil filter
-- 41078 1 Filter element
30
41426 1 2632SE -- Hydraulic Pump
41079 1 3346SE, 4046SE, 4555SE -- Hydraulic Pump
31 50002 3 Washer 10
32 53054 2 Spring washer 10
33 53060 2 Bolt 3/8-24×1.5-C
34
41889
1 ECU module
35 50524 4 Nut M5
36 53038 4 Washer 5
37 41081 1 Valve
38 50049 1 Nut, M10
39 50507 1 Bolt, SHCS M10 x 60
40 41062 1 Rubber Block
