“SE Series” Service and Parts ManualMarch 2017
Page IX
H
YDRAULIC
C
OMPONENTS
T
ORQUE
T
ABLE
NOTE: Always lubricate threads with clean hydraulic fluid prior to installation.
Use the following values to torque hydraulic components when a specific value is not
available. Always check for torque values in the following places before relying on the
Hydraulic Components Torque Table:
• parts drawings and service instructions in this manual.
• packaging and instruction sheets provided with new parts.
• instruction manuals provided by the manufacturer of the component being serviced.
Type: SAE
PORT SERIES
Cartridge Poppet Fittings Hoses
Ft. Lbs. Nm Ft. Lbs. Nm In. Lbs. Nm
#4 N/A N/A N/A N/A 135-145 15-16
#6 N/A N/A 10-20 14-27 215-245 24-28
#8 25-30 31-41 25-30 34-41 430-470 49-53
#10 35-40 47-54 35-40 47-54 680-750 77-85
#12 85-90 115-122 85-90 115-122 950-1050 107-119
#16 130-140 176-190 130-140 176-190 1300-1368 147-155
