E MERGENCY S YSTEMS AND P ROCEDURES
IF THE CONTROL SYSTEM FAILS WHILE THE PLATFORM IS ELEVATED,
USE THE EMERGENCY LOWERING PROCEDURE TO SAFELY LOWER THE
PLATFORM.
DO NOT CLIMB DOWN THE ELEVATING ASSEMBLY OR EXIT THE PLATFORM.
E MERGENCY S TOP
Figure 1-2: Emergency Stop Buttons
The machine is equipped with an EMERGENCY STOP
switch at the base controls and the platform control box.
• Press the EMERGENCY STOP switch at any time to stop all
machine functions.
• Turn switch clockwise to reset.
• Either switch will stop all machine functions.
• Both switches must be reset or machine will not operate.
E MERGENCY L OWERING
Figure 1-3: Emergency Lowering
The Emergency Lowering System is used to lower the
platform in case of power failure.
To lower the platform, pull the Emergency Lowering
Knob, located near the Base Control panel.
ART_4979
ART_5016
Emergency
Lowering
Handle
