Mec SE Series - Page 147

March 2017
Page C-19
“SE Series” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Main Platform Assembly -- 4046SE, 4555SE
ITEM PART NO. QTY DESCRIPTION
1
41534 1 4046SE -- Right Guardrail
41119 1 4555SE -- Right Guardrail
2 53056 5 Screw M5×12-h
3 53038 1 Washer 5
4 41120 1 Bumper
5 41121 2 Rivet
6 41357 2 Spring Pin
7
41535 1 4046SE -- Left Guardrail
41122 1 4555SE -- Left Guardrail
8
41123 1 4046SE -- Rear Guardrail
41123 1 4555SE -- Rear Guardrail
9 50396 12 Nut M6
10 50000 12 Washer 6
11 41124 1 Gate Latch
12 50021 1 Bolt M10×55
13 41125 1 Spring
14 41126 1 Gate
15 50002 1 Washer 10
16 50053 1 Nut M10
17 41127 1 Upper Hinge
18 50125 12 Bolt M6×55
19 41128 1 Lower Hinge
20
41770 1 4046SE -- Platform Weldment
41129 1 4555SE -- Platform Weldment
21 53014 6 Nut M8
22 50001 6 Washer 8
23 50290 8 Screw M8×45
24 41360 2 Roller Bracket
25 50017 6 Bolt M8×60
26 41359 2 Bearing 6204
27 41527 2 Circlip
28 41133 2 Roller
29 53061 2 Screw M4×16
30 50321 1 Screw M4×10
31 41134 1 Clip
32 41059 2 Wire Grip
33 91598 1 Outlet Cover
34 92007 1 Outlet, 15A 120V GFCI
35 91597 1 Outlet Box
-- 53040 4 Screw, HHSM #8 x .5"
36 92008 1 Strain Relief
