4046SE 4555SE
Working Height* 46 ft 14 m 51 ft 15.7 m
Platform Height 40 ft 12 m 45 ft 13.7 m
Maximum Drive Height 40 ft 12 m 45 ft 13.7 m
Stowed Height Top Guardrail 102 in. 2.6 m 102 in. 2.6 m
Rails Folded 79 in. 2.0 m 79 in. 2.0 m
Platform Floor 58 in. 1.48 m 58 in. 1.48 m
Guardrail Height 43.5 in. 1.11 m 43.5 in. 1.11 m
Toeboard Height 6 in. 15 cm 6 in. 15 cm
Machine Weight** (Unloaded) 6,820 lb 3,100 kg 7,190 lb 3,260 kg
Lift Capacity Total
550 lb 250 kg 500 lb 227 kg
Deck Extension Capacity
1 Pe
rson /
250lb (113 kg) 1 Person / 250lb (113 kg)
Maximum Occ
upants
2 2
Length-St
owed (Overall) 98 in. 2.5 m 112 in. 2.85 m
Length-Stowed (Ladder Removed) 89.5 in. 2.27 m 104 in. 2.65 m
Platform Length (Extended) 124.5 in. 3.16 m 139 in. 3.53 m
Platform Length (Retracted) 89.5 in. 2.27m 104 in. 2.65 m
Width (Overall) 47 in. 1.2cm 55 in. 1.4 cm
Platform Width (Outside) 44 in. 1.12 cm 44 in. 1.12 cm
Wheel Base 74 in 1.87 m 87 in 2.22 m
Turning Radius--Inside 0 in. 0 cm 0 in. 0 cm
Ground Clearance--Stowed 4 in 10 cm 4 in 10 cm
Ground Clearance--Elevated .7 in 2 cm .7 in 2 cm
Drive Speed
(Proportional)
Stowed 0-2.5 mph 0-4 km/h 0-2.5 mph 0-4 km/h
Raised or
extended
0-.5 mph 0-.8 km/h 0-.5 mph 0-.8 km/h
Gradability
25%/14° 25%/14°
Maximum Side Slope--Stowed 5° 5°
Tilt Sensor Settings 2° side-to-side; 3° fore-and-aft 2° side-to-side; 3° fore-and-aft
Ground Pressure/Wheel 167 psi
11.7 kg/cm
2
256 psi
18 kg/cm
2
Maximum Wheel Load 2948 lb 1340 kg 3076 lb 1395 kg
Occupied Floor Pressure 255 psf
1240 kg/m
2
194 psf
947 kg/m
2
Maximum Operating Wind Speed 28 mph / 12.5 m/sec (45 km/h) 28 mph / 12.5 m/sec (45 km/h)
Tire Size 15 x 5 inch/381 x 127 mm 15 x 5 inch/381 x 127 mm
Wheel Bolt Torque 19 ft-lb / 25.5 Nm 19 ft-lb / 25.5 Nm
Hydraulic Pressure 3000 psi/ 207 bar 3000 psi/ 207 bar
Power System Voltage 24 Volt DC / 300Ah 24 Volt DC / 300Ah
Battery Charger Input 110-230 V AC, 50-60 Hz 110-230 V AC, 50-60 Hz
Output 24 Volt DC 24 Volt DC
Batteries Four 12-Volt deep cycle; 300 Ah Four 12-Volt deep cycle; 300 Ah
M
ACHINE
S
PECIFICATIONS
Meets applicable requirements of ANSI A92.6-2006. *Working Height adds 6 feet (2 m) to platform height. **Weight may increase
with certain options.†Sheet material weight is part of the total platform capacity. is may limit capacity to one occupant.
“SE Series” Service and Parts Manual March 2017
